MWM KD 12 E and KD 12 Z KD12 Operating instructions and spare parts catalog

MWM KD 12 E and KD 12 Z KD12 Operating instructions and spare parts catalog
Image may differ in color or layout
MWM KD 12 E and KD 12 Z KD12 Operating instructions and spare parts catalog MWM KD 12 E and KD 12 Z KD12 Operating instructions and spare parts catalog
Item Number: WK-0271
In stock and ready for shipping
€25
Incl. VAT, excl. Shipping
or order directly
Condition:
New
Brand:
Bautz, Fendt, Hela, MWM, Ritscher
Dimensions:
DIN A5
Pages:
86 pages
Language:
German
Description
Combined operating instructions and spare parts list with fault table, care and maintenance for the motor KD 12 E and Z.

Engine is installed in the following tractors, among others: Bautz AW 240, Fendt F 12 GH, Hela D 112 and D 24, Ritscher 524, Wahl W 12 and W 22, Wesseler W 12 and W 24 and in other tractors.
You will receive a good quality bound book or brochure by postNo PDF, no CD and no loose sheet collection!
Table of Content
I. Vorwort
II. Leistungsangaben
1. Hauptdaten
2. Kolben und Lagerspiele
III. Beschreibung des Motors
1. Arbeitsweise
2. Motorenbeschreibung
IV. Inbetriebsetzung und Bedienung des Motors
a) Vorbereitung beim erstmaligen Anlassen odernach längerer Betriebspause
b) Anlassen mit Zündungpapier
c) Anlassen mit elektrischer Glühzündung
d) Beobachtung am Motor während des Betriebes (10 Gebote)
e) Abstellen
f) Arbeiten nach dem Abstellen
V. Winterbetrieb
VI. Betriebsstörungen und Ihre Behebung
Störungstabelle, Wartungstafel
VII. Pflege des Motors
1. Schmierstoffe
2. Kraftstoffe
3. Kraftstoff-Filter
Vorschläge zur Kraftstofflagerung
4. Kühlwasser
5. Luftfilter
VIII. Instandhaltung
1. Einspritzventil
2. Einspritzpumpe
3. Ein- und Auslassventil
4. Lager
5. Kolben
6. Ausbau der Kurbelwelle
7. Ausbau der Nockenwelle
8. Ausbau der Zahnradölpumpe
9. Ausbau des Schwungrades
10. Aufschleifen des Schwungrades
11. Wasserpumpe
IX. Einzelteilverzeichnis
Tafelverzeichnis
Anleitung zum richtigen Bestellen von Ersatzteilen
