Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog

Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog
Image may differ in color or layout
Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog Adler MB 150, 200, 201, 250 and M 2011 spare parts list spare parts catalog
Item Number: WK-0226
In stock and ready for shipping
€22
Incl. VAT, excl. Shipping
or order directly
Condition:
New
Brand:
Adler
Dimensions:
DIN A4
Pages:
68 pages
Language:
German
Description
Spare parts list for the Adler motorcycles MB 150, MB 200, MB 201, MB 250 and M 2011.
You will receive a good quality bound book or brochure by postNo PDF, no CD and no loose sheet collection!
Table of Content
1 Motor: Motor/Getriebe und Aufhängung
2 Motor: Zylinderkopf, Zylinder, Kurbelwelle
3 Motor: Zylinderkopf, Zylinder, Kurbelwelle
4 Motor: Kupplung, Kupplungsausrückung
5 Motor: Tachometer-Antrieb
6 Motor: Licht- und Zündanlage
7 Motor: Bing-Vergaser
8 Motor: Amal-Vergaser
9 Motor: Gehäuse für Motor/Getriebe, vollst.
10 Motor: Getrieberäder und -wellen, Getriebeschaltung, Kickstarter
11 Rahmen und Hinterradfederung
12 Fußraste, Bremsfußhebel, Kippständer
13 Vorderradgabel, Steuersatz, Steuerdämpfer
14 Steuersatz, Steuerdämpfer
15 Linke und rechte Vordergabelscheide
16 Vorderrad- und Hinterradschutzblech
17 Lenker, Seilzüge, Fußbremsstange
18 Vorderrad mit Lagerung und Bremse
19 Hinterrad mit Lagerung und Bremse
20 Hinterradantriebsflansch vollst. Flansch für Kettenschutz
21 Kennezeichentafel, Kettenschutz
22 Sattel
23 Kraftstoffbehälter
24 Auspuffrohr, Auspufftopf
25 Elektrische Ausrüstung
26 Elektrische Ausrüstung
27 Werkzeug, Werkzeugkasten, Zubehör
